BG 5195 BEN / A (2011-05) TPG261.oi 87
Transmit: ADC <CR>[<LF>]
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Receive: [x]x.xxxx,[x]x.xxxx,x.xxxx,x.xxxx <CR><LF>
│ │ │ │
│ │ │ └ ADC channel 4
│ │ │ identification
│ │ │ Gauge 2
│ │ │ [0.0000 ...
│ │ │ 5.0000 V]
│ │ │
│ │ └─ ADC channel 3
│ │ Gauge 1 identification
│ │ [0.0000 ... 5.0000 V]
│ │
│ └─ ADC channel 2
│ Measurement signal
│ gauge 2
│ [0.0000 ... 11.0000 V]
│
└─ ADC channel 1
Measurement signal gauge 1
[0.0000 ... 11.0000 V]
ADC test
