2.2 Video / Audio Input Signals
2.2.1 PC input signal requirements
Pixel Rate Capability 86 MHz
VGA Sync Input TTL level, separate H/V sync only, “+” or “-” polarity, terminated with ≥ 2.2kΩ impedance
HDMI Input TMDS channel:
¾ Carries video data.
¾ Signaling method: According to DVI 1.0 specification. Single-link (Type A HDMI).
¾ Video pixel rate: 25 MHz to 165 MHz (Type A)
DDC channel:
¾ Allows source to interrogate capabilities of sink.
¾ I²C signaling with 100 kHz clock.
¾ E-EDID data structure according to EIA/CEA-861B and VESA Enhanced ED
VGA Analog RGB
Level
0 ~ 700mV linear, positive polarity, terminated with 75Ω impedance.
I²C DDC signal DDC2B required, DDC serial Data & Clock, DDC components are connected to both
display VCC and DDC +5V (from PC via video cable), that the PC can read the DDC
data also when the display is powered off. To prevent current feedback into PC,
blocking diodes are required at display side.
Preset Timings 95 preset modes sets, 8 factory preset mode sets, timing; size and centering have been
pre-aligned in factory according to specifications.
Preset Mode
Definition
¾ Need to support those timing:
¾ 1360X768 should not be scaled. The position must be center. The outside area of
display must be black.
¾ Required resolutions and timings:
PC modes:
It can not test, if timing not in this timing list
Req. ID
Resolution According to VESA DMT Standard
Specification
Wish/Req. Test Pattern
Resolution
Refresh
Rate
Horizontal
Frequency
Pixel Clock
PCRES1 640 x 350 85 Hz 37.9 kHz 31.500 MHz W DMT0685F
PCRES2 640 x 400 85 Hz 37.9 kHz 31.500 MHz W DMT0685D
PCRES3 720 x 400 85 Hz 37.9 kHz 35.500 MHz W DMT0785H
PCRES4 640 x 480 60 Hz 31.5 kHz 25.175 MHz R DMT0660
PCRES5 640 x 480 72 Hz 37.9 kHz 31.500 MHz W DMT0672
PCRES6 640 x 480 75 Hz 37.5 kHz 31.500 MHz R DMT0675
PCRES7 640 x 480 85 Hz 43.3 kHz 36.000 MHz W dmt0685
PCRES8 800 x 600 56 Hz 35.1 kHz 36.000 MHz W DMT0856
PCRES9 800 x 600 60 Hz 37.9 kHz 40.000 MHz R DMT0860
PCRES10 800 x 600 72 Hz 48.1 kHz 50.000 MHz W DMT0872
PCRES11 800 x 600 75 Hz 46.9 kHz 49.500 MHz W DMT0875
PCRES12 800 x 600 85 Hz 53.7 kHz 56.250 MHz W DMT0885
PCRES13 800 x 600 120 Hz 76.3 kHz 73.250 MHz W CVR0812.xml
