The pictures are for reference only, please refer to the actual packaging
items.
Inside escutcheon
Outside escutcheon
3. Get to know your EasyKey
①
Door lock status
indicator
②
Infrared sensor
③
Keypad
④
Mute button
⑤
Outside forced lock
button
⑥
Handle
⑦
Low battery voltage
indicator
⑧
Card reader
⑨
Keyhole
⑩
Emergency power supply
interface
①
Battery cover
②
Battery compartment
③
Auto/Manual mode
toggle switch
④
Reboot button
⑤
Communication and
network module
interface
⑥
【
OPEN/CLOSE
】
button
⑦
Rotary knob
⑧
Handle
4
5
8
6
7
1
2
3
6
2
5
4
1
3
9
10
