Philips Efficia CM Series User Manual

Monitoring Anesthetic and Respiratory Gases
Efficia CM Series Rack and Modules Instructions for Use 6-5
Gas Waveform Menu
Gas Waveform Menu
Use the Waveform Menu to:
• Change the speed of the Gas measurement waveform
• Change the scale of the Gas measurement waveform
• Select the corresponding measurement unit, CO
2
, N
2
O or anesthetic.
For information on other settings in the Gas measurement waveform menu, see the
appropriate section in this chapter.
To open the Gas measurement Waveform Menu:
• Select any Gas waveform on the screen. The selected Gas Waveform Menu
appears, and the current settings are displayed.
The Gas measurement module has the following waveforms:
•O
2
•CO
2
•N
2
O
• AGT.xxx
1
• AGT2.xxx
2
The available waveforms depend on the measurement module being used. Modules with
the dual agent measurement (AGT and AGT2) can identify up to two anesthetics being
used at the same time and differentiate them in waveforms and number panes. Modules
with single agent detection or without agent identification use only the field AGT.
The waveform type selected will be displayed at the top-left corner of the waveform
pane. The waveform labels and color depends on the selected waveform and the
detected anesthetics.
1.
xxx will be replaced by the name of the anesthetic being used.
2.
xxx will be replaced by the name of the anesthetic being used.
Anesthetic Label Color
O
2
O
2
Green
CO
2
CO
2
Yellow
N
2
ON
2
O Blue
Halothane HAL Red
Sevoflurane SEV Yellow
Isoflurane ISO Dark Purple
Enflurane ENF Orange
Desflurane DES Blue
AGT AGT White
AGT2 AGT2 White
