INTELIA 07 DISASSEMBLY
Saeco International Group Rev. 01 / September 2011 Page / 11
03
To extract the top support of the appliance, press
on the grinding adjustment spindle (A) and turn the
support anticlockwise until it unhooks.
Turn the grinder blades anticlockwise out of the support.
Turn the grinder blades clockwise out of the support. The
bayonet connections can be accessed from the rear.
For a standard adjustment, both markings must be
aligned.
7.4. Grinder blades
A
B
