15.4 LIST OF CHECKED PARTS OF GENERATOR S/N
Please add this list to returned parts.
ENK2 phase 1 1 - 2 ❒ open ❒ welded
phase 2 3 - 4 ❒ open ❒ welded
phase 3 5 - 6 ❒ open ❒ welded
EN : R1 ❒ open
: R2 ❒ open
: R3 ❒ open
ENF1 L1 – T1 ❒ open ❒ welded
L2 – T2 ❒ open ❒ welded
L3 – T3 ❒ open ❒ welded
ENF2 L1 – T1 ❒ open ❒ welded
L2 – T2 ❒ open ❒ welded
L3 – T3 ❒ open ❒ welded
ENK1 phase 1 2 – 1 ❒ open ❒ welded
phase 2 4 – 3 ❒ open ❒ welded
phase 3 6 – 5 ❒ open ❒ welded
Rectifier EQV5 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
IGBT 1 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
IGBT 2 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
IGBT 3 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
IGBT 4 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
Diode V501 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
Diode V502 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
Diode V503 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
Diode V504 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
Resistors R506/507/508 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
Resistors R509/510/511 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
Cable harness EQ ❒ 2 = OK ❒ 1 = defective E2Q ❒ 2 = OK ❒ 1 = defective
>> Converter EQ ❒ OK ❒ defective unit barcode# frontal: _________
E2Q ❒ OK ❒ defective unit barcode# rear (65/80kW only):________
Res. capacitor C3 EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
Res. capacitor
C13
EQ ❒ OK ❒ defective E2Q ❒ OK ❒ defective
H.V. cable ❒ OK ❒ defective
X-Ray tube 1 ❒ OK ❒ defective tube type:________ tube S/N:________
X-Ray tube 2 ❒ OK ❒ defective tube type:________ tube S/N:________
H.V. transformer ❒ OK ❒ defective tank S/N:________
Converter test kit OPTIMUS for OPTIMUS 50/65/80 gen‐
erators release 3.x with converters 4512 104 7231x
