MENU SYSTEM : MENU OPERATION
4
02.9687.0001 C 31 October 2013 67
DMX
DMX Data and
Pan/Tilt Mode
DATA
Note: Channel and Dimmer
information displayed
simultaneously
Channel XXX
DMX Channel
XXX
Data
Dimmer XXX
Data
Wireless? Is optional
wireless DMX module
attached? (Note DMX
modules sold separately)
No
Yes
Pan/Tilt
Pan/Tilt Options Swap
Swap Pan & Tilt
ON
OFF
(default)
Inv Pan
Invert Pan
ON
OFF
(default)
Inv Tilt
Invert Tilt
ON
OFF
(default)
Fixture
Displays fixture
information,
condition or
downloads new
software
Status
Status/Error Display
Scrolls error messages or
displays
"No Errors"
Re-Calibrate
Recalibrate
OK?
LumId
Luminaire ID
XXXX
Luminaire ID Number
Version
Software Version
XX/XX/XX
Version Date
Fixt Hrs
Fixture Hours On (powered)
XXXX
Hours
Download
Download Program to
Luminaires
OK?
Table 4-1: Menu System Chart (Continued)
1st Level 2nd Level 3rd Level 4th Level 5thLevel
