Manual
Manual
Commands
Note: Manual is
Disabled if
DMX512 signal
is present.
Pan
Pan Motor
XXXXX Data
Tilt
Tilt Motor
XXXXX Data
Dimmer
Dimmer Wheel
XXXXX Data
Strobe
Strobe
XXXXX Data
Cyan
Cyan Color Wheel
XXXXX Data
Yellow
Yellow Color Wheel
XXXXX Data
Magenta
Magenta Color Wheel
XXXXX Data
Color Whl
Fixed Color Wheel
XXXXX Data
Rot Gobo
Rotating Gobo Select
XXXXX Data
Index
Rotating Gobo Index
XXXXX Data
Fixed Gobo
Select Fixed Gobo
XXXXX Data
Edge
Edge
XXXXX Data
Zoom
Zoom
XXXXX Data
Iris
Beam Iris
XXXXX Data
Frost
Frost
XXXXX Data
Prism
Prism
XXXXX Data
Prism Rot
Prism Rotation
XXXXX Data
Test*
System Test
Note: Test is
Disabled if
DMX512 signal
is present.
ALL SEQ
Sequence Through All Tests
RunTest Press [Menu] to
stop tests
Pan/Tilt
Pan/Tilt
RunTest
Pan
Pan
RunTest
Tilt
Tilt
RunTest
Strobe
Strobe
RunTest
Dimmer
Dimmer
RunTest
Table 4-1: Menu System Chart (Continued)
1st Level 2nd Level 3rd Level 4th Level 5thLevel
- Continued Next Page -
