MENU SYSTEM : MENU OPERATION
4
02.9687.0001 C 31 October 2013 69
Test*
System Test
(continued)
Note: Test is
Disabled if
DMX512 signal
is present.
Cyan
Cyan Color Wheel
RunTest Press [Menu] to
stop tests
Yellow
Yellow Color Wheel
RunTest
Magenta
Magenta Color Wheel
RunTest
Color Mix
Color Wheel Color Mixing
RunTest
Color Whl
Fixed Color Wheel
RunTest
Fix Gobo
Fixed Gobo Wheel
RunTest
Rot Gobo
Rotating Gobo Wheel
RunTest
Gobo Index
Rotating Gobos Indexes
RunTest
Edge
Edge
RunTest
Zoom
Zoom
RunTest
Iris
Beam Iris
RunTest
Frost
Frost
RunTest
Prism
Prism
RunTest
Lamp
Lamp (Disables Pan
and Tilt for lamp adjustment)
RunTest
Encoder
Encoder (Allows
hand movement to check
values)
Pan Value
Tilt Value
Temps
Luminaire operational
temperatures
MCN Value (00 Deg C)
DRB Value (00 Deg C)
DRF Value (00 Deg C)
Fan Speeds H1 Fan Head Fan 1 Speed is displayed
H2 Fan Head Fan 2 Speed is displayed
H3 Fan Head Fan 3 Speed is displayed
H5 Fan Head Fan 5 Speed is displayed
H6 Fan Head Fan 6 Speed is displayed
L1 Fan Lamp Fan 1 Speed is displayed
L2 Fan Lamp Fan 2 Speed is displayed
*Refer to “Diagnostic Tests” on page 75 for more information.
Table 4-1: Menu System Chart (Continued)
1st Level 2nd Level 3rd Level 4th Level 5thLevel
