Philips VR109/55 - Main 3;4 Schematic Diagram; Main 3;4 Schematic Diagram Parts Location Guide

MAIN 3/4 Schematic Diagram Parts Location Guide
Ref No. Position Ref No. Position
C253 N-3 L302 O-1
C255 N-2 L303 O-1
C256 N-2 L304 O-1
C301 O-1 L306 P-3
C302 O-2 L312 P-4
C303 O-2 L401 N-1
C304 N-1 L402 M-2
C305 O-1
C306O-1Q302O-1
C307O-1Q303O-1
C308O-1Q304O-1
C310 O-1 Q305 P-2
C311 O-1 Q307 P-3
C312 O-1 Q315 P-4
C313O-1Q401M-2
C314O-1Q402N-1
C315P-1Q403N-1
C317P-2Q404M-1
C318P-2Q405M-1
C319 P-2
C320P-2R253M-2
C321P-2R257N-2
C322P-2R303O-2
C323P-2R304O-2
C324P-2R305N-1
C325P-2R306O-1
C326P-2R307O-1
C328P-2R308O-1
C330Q-2R309O-1
C331P-3R310O-1
C332P-3R311O-1
C333P-3R312O-1
C334P-3R313O-2
C335P-3R314O-2
C336P-3R315O-1
C337P-3R316O-1
C338P-3R317O-1
C339 P-3 R318 P-1
C340 P-3 R319 P-1
C341 O-4 R320 P-1
C342 P-4 R321 P-4
C344 O-3 R322 P-4
C345 O-3 R325 P-2
C346 O-3 R326 P-2
C348 O-3 R327 P-2
C349O-3R328Q-3
C350O-3R329O-1
C351O-3R330O-1
C352 O-3 R331 P-2
C353O-4R334O-4
C354O-4R335O-3
C355P-2R336O-3
C357 P-2 R341 P-2
C381P-3R401M-2
C401 N-2 R402 M-2
C403 N-2 R403 M-2
C404 N-2 R404 M-2
C405 N-2 R405 N-2
C406 N-2 R406 N-2
C407 M-2 R408 N-2
C408 M-2 R409 M-2
C409 M-2 R410 M-1
C410 M-1 R411 N-1
C411 N-1 R412 N-1
C412 N-1 R413 M-1
C413 N-2 R414 N-2
C414 N
-
1R415N
-
2
CAPACITORS COILS
TRANSISTORS
RESISTORS
Main 3/4 Schematic Diagram
THE SAME VOLTAGE FOR
BOTH PLAY & REC MODES.
INDICATES THAT THE VOLTAGE
IS NOT CONSISTENT HERE.
MODE: SP/REC
PLAY MODE
REC MODE
1
2
3
5.0
5.0
(2.5)
〜
“ “ = SMD
1-11-9 1-11-10 1-11-11
H67T0SCM3
Comparison Chart of
Models and Marks
MODEL MARK
VR109/55 A
VR109/75 B
