Philips VR109/55 - Set Mechanical Parts List

SET MECHANICAL PARTS LIST
For not coded parts please use PHILIPS
standard components.
The standard Sparepart Catalogue can be
ordered with Service Code 3103 785 20730.
Comparison chart of models and marks
Model No. Mark
VR109/55 A
VR109/75 B
! Ref. No. Mark Description ServiceCode
A1X A FRONT ASSEMBLY 9965 000 06518
A1X B FRONT ASSEMBLY 9965 000 06563
A2 CASE, TOP(JPN GRAY) 9965 000 05231
B359 CLEANER LEVER MK9 9965 000 05233
B360 CLEANER ROLLER MK9 9965 000 06561
B529 CLEANER ASSY MK9 9965 000 05235
2B5 PLATE, SHIELD(U21) H5700UD 9965 000 05630
2L011 SCREW 3X10 4822 502 14666
2L021 4822 502 30752
2L031 M 3 X 8 4822 502 14012
ACCESSORIES
X1 REMOTE 364/CRC004 9965 000 06519
X3 CONNECT. CABLE PAL 4822 320 50377
! X20 A OWNER’S MANUAL VR109/55 9965 000 06520
! X20 B OWNER’S MANUAL VR109/75 9965 000 06564
! ... Safety component, use only this type
2000-07-05 1-19-1 H67T0CA
H67T0PD/1AD
