STANDARD MAINTENANCE
Service Schedule of Components
h: Hours ❍: Check ●: Change
Deck Periodic Service Schedule
Ref. No. Part Name 1,000 h 2,000 h 3,000 h 4,000 h
B2 Cylinder Assembly ❍●❍●
B3 Loading Motor Assembly ●
B8 Pulley Assembly ●●
B27 Tension Lever Assembly ●●
B31 AC Head Assembly ●
B32, B339 Reel (T), Reel (S) ●
B37 Capstan Motor ●●
B52 Capstan Belt ●●
*B73 FE Head CBA ●
B133 Idler Assembly ●●
B410 Pinch Arm (A) Assembly ●●
B414 Main Brake S Assembly ●●
B416 Main Brake T Sub Assembly ●●
B525 Loading Belt ●●
Notes:
1. Clean all parts for the tape transport (Upper Drum with Video Head / Pinch Roller / Audio Control Head / Full
Erase Head) using 90% Isopropyl Alcohol.
2. After cleaning the parts, do all DECK ADJUSTMENTS.
3. For the reference numbers listed above, refer to Deck Exploded Views.
* B73 ------ VCR Model only
