ELECTRICAL PARTS LIST
For not coded parts please use PHILIPS
standard components.
The standard Sparepart Catalogue can be
ordered with Service Code 3103 785 20730.
1. Tolerance of Capacitors and Resistors are noted with
the following symbols.
C..........±0.25% D..........±0.5% F..........±1%
G..........±2% J..........±5% K..........±10%
M..........±20% N..........±30% Z..........+80/-20%
2. LED EXCLUSIVE ( TYPE A) and ( TYPE B) :
When it is necessary to replace one or more of the
following diodes, all five should be replaced: D510,
D511, D512, D513, D514.
Comparison chart of models and marks
Model No. Mark
VR109/55 A
VR109/75 B
Main CBA (MCV-A)
!
Ref. No. Mark Description ServiceCode
Main CBA (MCV-A) ------------
CAPACITORS
!
C001 METALLIZED FILM CAP. 0.068µF/2 9965 000 06521
!
C003 SAFTY CAP. 2200pF/250V 9965 000 06522
C004 A 1000UF 20% 400V 4822 124 12446
C004 B ELECTROLYTIC CAP. 22µF/400V M( 9965 000 06566
C006 B CERAMIC CAP. SL J 56pF/1KV 9965 000 06567
C357 CERAMIC CAP.(AX) SL J 10pF/50V 9965 000 06536
C409 CERAMIC CAP. B K 470pF/100V 9965 000 06523
C414 CERAMIC CAP.(AX) B K 820pF/50V 9965 000 06552
C534 CERAMIC CAP.(AX) SL J 10pF/50V 9965 000 06536
C542 CERAMIC CAP.(AX) SL J 10pF/50V 9965 000 06536
C860 A CERAMIC CAP.(AX) B K 82pF/50V 9965 000 06556
CONNECRTORS
CN251 FE CONN. TOP 4P 04FE-BT-VK-N 9965 000 05244
CN501 CABLE CONN. 2P 4822 265 10994
CN502 FE CONN.TOP 7P 07FE-BT-VK-N 9965 000 05245
CN503 J3TMA08TG002 4822 265 11242
CN504 FE CONN.TOP 9P 09FE-BT-VK-N 9965 000 05246
CN505 CONNECTOR BASE 4P TUC-P04P-
B1
9965 000 05247
DIODES
TYPE A
D510 LTL-16KPE-P 4822 130 82978
D511 LTL-16KPE-P 4822 130 82978
D512 LTL4231N 4822 130 10685
D513 LTL-16KPE-P 4822 130 82978
D514 LTL-16KPE-P 4822 130 82978
TYPE B
D510 LT6311G-41 4822 130 11652
D511 LT6311G-41 4822 130 11652
D512 LT6321-41 4822 130 11649
D513 LT6311G-41 4822 130 11652
D514 LT6311G-41 4822 130 11652
D001 1N5061 4822 130 31933
D002 1N5061 4822 130 31933
!
Ref. No. Mark Description ServiceCode
D003 1N5061 4822 130 31933
D004 1N5061 4822 130 31933
D005 BYV96E 5322 130 34979
D006 1SS133 4822 130 32778
D007 1SS133 4822 130 32778
D008 1SS133 4822 130 32778
D009 1SS133 4822 130 32778
D010 A MTZJ33D 4822 130 81729
D011 BYV95C 4822 130 41487
D013 BYV95C 4822 130 41487
D014 ERB81-004 4822 130 80601
D015 MTZJ9.1C 4822 130 80319
D019 ZENER DIODE MTZJT-775.6B 9965 000 05249
D052 1SS133 4822 130 32778
D053 1N5061 4822 130 31933
D056 ZENER DIODE MTZJT-775.1C 9965 000 05694
D060 MTZJ9.1C 4822 130 80319
D301 1SS133 4822 130 32778
D503 1SS133 4822 130 32778
D504 1SS133 4822 130 32778
D505 1SS133 4822 130 32778
D506 1SS133 4822 130 32778
D551 LED SIR-563ST3F P 9965 000 05250
D701 MTZJ33D 4822 130 81729
ICS
!
IC001 LTV817B-F 4822 130 11655
IC301 IC:Y/C/A LA71592M 9965 000 05625
IC501 MICROCONTROLLER 8BIT
CXP88140A
9965 000 06553
IC503 LM324N 4822 209 80587
IC505 IC:MEMORY BR24C02F-W 9965 000 06554
IC611 IC LB11880 9965 000 05253
IC851 IC, ON SCREEN LC74783-9173 9965 000 06555
COILS
!
L002 33MHLF002 4822 157 11597
L003 BEAD CORE 4822 526 10685
L004 BEAD CORE 4822 526 10685
L007 BEAD CORE 4822 526 10685
L009 CHOKE COIL 47µH-K 9965 000 05627
L302 47µH-K-26T 4822 157 11509
L303 39µH-K 4822 157 10325
L304 100µH 4822 157 10649
L306 INDUCTOR 47µH-K-5FT 9965 000 05705
L312 15µH-K-26T 4822 157 11511
L401 INDUCTOR 47µH-K-5FT 9965 000 05705
L402 CHOKE COIL 47µH-K 9965 000 05627
L502 CHOKE COIL 47µH-K 9965 000 05627
L503 CHOKE COIL 47µH-K 9965 000 05627
L701 10µH 4822 157 10889
L704 CHOKE COIL 47µH-K 9965 000 05627
L851 27µH 4822 157 10891
L853 220UF 4822 157 10347
TRANSISTORS
Q001 A FET FS2KM-18A 9965 000 05255
Q001 B FET FS1KM-18A 9965 000 06568
Q002 2SC2785K 4822 130 11692
Q003 2SC2785K 4822 130 11692
Q004 2SC2785J 4822 130 11647
Q054 2SC2120Y 4822 130 42292
Q056 TRANSISTOR BN1F4M-T 9965 000 05388
Q057 2SA1015GR 4822 130 11101
!
... Safety component, use only this type
2000-07-05 1-17-1 H67T0EL
H67T0PD/1AD
