! Ref. No. Mark Description ServiceCode
Q302 KTC3193Y 4822 130 10102
Q303 KTC3193Y 4822 130 10102
Q304 KTC3193Y 4822 130 10102
Q305 2SA1015GR 4822 130 11101
Q307 2SA1175J 4822 130 11646
Q315 2SC2785J 4822 130 11647
Q401 2SA1015GR 4822 130 11101
Q402 2SC2120Y 4822 130 42292
Q403 TRANSISTOR BN1F4M-T 9965 000 05388
Q404 2SC3331T 4822 130 10097
Q405 2SC3331T 4822 130 10097
Q503 PHOTO TRANSISTOR ST-304L-A 9965 000 05257
Q504 PHOTO TRANSISTOR ST-304L-A 9965 000 05257
Q505 2SC2785K 4822 130 11692
Q506 TRANSISTOR BA1F4M-T 9965 000 05389
Q508 TRANSISTOR BN1F4M-T 9965 000 05388
SWITCHES
SW501 KSM0614B 4822 276 13954
SW502 KSM0614B 4822 276 13954
SW503 KSM0614B 4822 276 13954
SW505 KSM0614B 4822 276 13954
SW506 PUSH SWITCH SPPB61 4822 276 13777
SW507 ROTARY MODE SWITCH 9965 000 05258
MISCELLANEOUS
2B1 HOLDER, L.E.D.(U19) H3700UD 9965 000 06560
2B3 HOLDER, SENSOR(2) 9965 000 05239
2B8 BUSH, LED(E) 4822 532 12987
2B11 A HEATSINK 9965 000 05241
2B34 PLATE, EARTH(U21) 9965 000 05240
2L041 A SCREW 3X8 4822 502 14667
! AC001 A AC CORD 9707020 4822 321 11411
! AC001 B AC CORD LA-1865 9965 000 06565
! F001 21801.6(1.6A) 4822 070 31602
FH001 FUSE HOLDER MSF-015 4822 256 10461
FH002 FUSE HOLDER MSF-015 4822 256 10461
JK751 4822 264 10286
JK751 4822 264 10286
PS501 PHOTO INTERRUPTER RPI-302 9965 000 05254
RS501 PIC-26042LU 4822 130 11648
! SA001 JVR-10N471K 4822 252 11373
! T001 A PULSE TRANS SA-90311D 9965 000 06557
! T001 B PULSE TRANS SA-90309E 9965 000 06569
TU701 A TUNER UNIT TMDG1-802A 9965 000 06558
TU701 B TUNER UNIT TMDG1-602A 9965 000 06570
X302 4 433 619 MHZ 4822 242 10695
X501 32.768KHZ 4822 242 10925
X502 13.300857MHZ 4822 242 10468
Function CBA (MCV-B)
! Ref. No. Mark Description ServiceCode
Function CBA (MCV-B) ------------
CN651 CONNECTOR 4P TUC-P04X-B1 9965 000 05261
SW651 KSM0614B 4822 276 13954
SW652 KSM0614B 4822 276 13954
SW653 KSM0614B 4822 276 13954
SW654 KSM0614B 4822 276 13954
SW655 KSM0614B 4822 276 13954
SW656 KSM0614B 4822 276 13954
SW658 KSM0614B 4822 276 13954
SW659 KSM0614B 4822 276 13954
! ... Safety component, use only this type
2000-07-05 1-17-2 H67T0EL
H67T0PD/1AD
