Philips VR109/55 - Waveforms

P L L ‑ C L K    0 . 1 V X 1 0      2 m s e c
WAVEFORMS
1-12-1 U21WFF
WF1
V-OUT E-E
10usec 50mV x 10
(TP751 of Main CBA)
WF1
UPPER
WF2
LOWER
V-OUT 0.1V x 10
RF-SW 0.5V x 10
50usec
(TP751 of Main CBA)
(TP302 of Main CBA)
WF5
C-PB 10mV x 10
RF-SW 0.5V x 10
5msec
UPPER
LOWER
WF2
(TP302 of Main CBA)
(TP301 of Main CBA)
