Philips VR109/55 - Deck Parts List

DECK PARTS LIST
For not coded parts please use PHILIPS
standard components.
The standard Sparepart Catalogue can be
ordered with Service Code 3103 785 20730.
Ref. No. Description ServiceCode.
2B6 DECK GROUNDING PLATE U21 9965 000 05262
2L051 M 3 X 6 4822 502 14009
B1 CHASSIS ASSY MK9 9965 000 05263
B2 CYLINDER ASS’Y MK9 PAL 2HD 2SP 9965 000 05651
B3 LOADING MOTOR ASSY MK9 9965 000 05265
B4 L MOTOR HOLDER MK9 9965 000 05266
B8 PULLEY ASSY MK9 9965 000 05267
B9 MOVING GUIDE S PREP. MK9 9965 000 05268
B10 MOVING GUIDE T PREP. MK9 9965 000 05269
B11 LOADING ARM T ASSY MK9 9965 000 05270
B12 LOADING ARM S ASSY MK9 9965 000 05271
B27 TENSION LEVAR SUB ASSY MK9 9965 000 05272
B31 AC HEAD ASS’Y MK9(TVCR) 9965 000 05632
B32 REEL T ASSY MK9 9965 000 05274
B35 TAPE GUIDE ASSY MK9 9965 000 05275
B38 MODE LEVER A ASSY MK9 90 9965 000 05277
B46 REV SPRING MK9 9965 000 05278
B52 CAP BELT MK9 9965 000 05279
B73 FE HEAD(MK9) HVFHP0041A 9965 000 05372
B74 PRISM 2 MK9 9965 000 05280
B121 WORM MK9 9965 000 05281
B126 PULLEY MK9 9965 000 05282
B133 IDLER ASSY MK9 9965 000 05283
B148 TG CAP 4822 462 11189
B300 FL ASSY MK9 9965 000 05284
B303 F DOOR OPENER MK9 9965 000 05285
B304 DOOR OPENER A MK9 9965 000 05286
B308 SLIDER SHAFT 4822 535 10645
B313 C.DRIVE SPRING MK9 9965 000 05287
B319 CASSETTE SPRING MK9 9965 000 05288
B319 CASSETTE SPRING MK9 9965 000 05288
B339 REEL S ASSY MK9 9965 000 05289
B344 CASSETTE GUIDE R MK9 9965 000 05290
B345 CASSETTE GUIDE L MK9 9965 000 05291
B347 GUIDE HOLDER MK9 9965 000 05292
B350 SLIDER GEAR 4822 522 10768
B352 C DRIVE LEVER MK9 9965 000 05293
B354 SLIDER R MK9 9965 000 05294
B355 SLIDER L MK9 9965 000 05295
B361 CL POST MK9 9965 000 05296
B401 VH CONNECTOR 4AN MK9 9965 000 05297
B402 VH CONNECTOR 4B MK6 4822 265 11332
B403 ACH CONNECTOR AN(9P) MK9 9965 000 05298
B403 ACH CONNECTOR AN(9P) MK9 9965 000 05298
B404 ACH CONNECTOR B(9P) MK9 9965 000 05299
B404 ACH CONNECTOR B(9P) MK9 9965 000 05299
B405 ACH CONNECTOR AN(7P) MK9 9965 000 05300
B406 ACH CONNECTOR B(7P) MK9 9965 000 05301
B410 PINCH ARM(A) ASSY MK9 9965 000 05302
B411 PINCH SPRING MK9 9965 000 05303
B414 M BRAKE S ASSY MK9 9965 000 05304
B416 M BRAKE T ASSY MK9 9965 000 05305
B417 TENSION SPG MK9 9965 000 05306
B420 REC ARM MK9 9965 000 05373
B421 REC ARM SPRING MK6 4822 492 11607
B423 CYLINDER SHIELD MK9 9965 000 05307
B425 LOCK LEVER SPRING MK9 9965 000 05308
Ref. No. Description ServiceCode.
B426 KICK PULLEY MK9 9965 000 05309
B427 KICK SPRING MK9 9965 000 05310
B472 SLIDER R ASSY MK9 9965 000 05311
B473 SLIDER L ASSY MK9 9965 000 05312
B475 BT ARM ASSY MK9 9965 000 05313
B476 REC ARM ASSY MK9 9965 000 05374
B480 PINCH ARM(B) ASSY MK9 9965 000 05314
B481 C.DRIVE SUB GEAR MK9 9965 000 05315
B482 CASSETTE PLATE MK9 9965 000 05316
B483 LOCK LEVER MK9 9965 000 05317
B484 REEL SHAFT B ASSEMBLY MK9 9965 000 06559
B485 INSULATION CAP B MK9 9965 000 05319
B487 BAND BRAKE MK9 9965 000 05320
B488 MODE LEVER A MK9 9965 000 05321
B489 FF RACK MK9 9965 000 05322
B490 FF RACK SPG MK9 9965 000 05323
B491 CAM GEAR(A) MK9 9965 000 05324
B492 MODE GEAR MK9 9965 000 05325
B493 C DRIVE GEAR MK9 9965 000 05326
B494 DOOR OPENER B MK9 9965 000 05327
B495 FIRST GEAR MK9 9965 000 05328
B496 SECOND GEAR MK9 9965 000 05329
B498 M LEVER HOLDER MK9 9965 000 05330
B499 T LEVER HOLDER MK9 9965 000 05331
B500 CENTER PULLEY MK9 9965 000 05332
B501 WORM HOLDER MK9 9965 000 05333
B502 CAM GEAR(B) MK9 9965 000 05334
B504 P.S.W. F 4822 532 13158
B506 INSULATION CAP A MK9 9965 000 05336
B507 TA WASHER MK9 9965 000 05337
B508 S BRAKE SPG MK9 9965 000 05338
B509 MODE LEVER HOLDER A MK9 9965 000 05339
B511 JOINT SPRING MK9 9965 000 05340
B513 CAM WASHER MK9 8*3.1*0.5 9965 000 05341
B514 SCREW:SLIDER R MK7 4822 502 14546
B516 REEL WASHER MK9 5*2.1*0.5 9965 000 05342
B517 P.S.W. F 4822 532 13158
B518 P.S.W. F 4822 532 13158
B519 P.S.W. F 4822 532 13158
B520 T BRAKE SPG MK9 9965 000 05343
B521 SOFT SPG MK9 9965 000 05344
B522 TG POST ASSY MK9 9965 000 05345
B523 FIRST POST ASSY MK9 9965 000 05346
B524 MOTOR PCB ASSY(M) MK9 9965 000 05347
B525 LDG BELT(B) MK9 9965 000 05348
B526 E RING 9965 000 05349
B530 REEL SPACER MK9 5.7*2.7*0.5 9965 000 06562
B531 JOINT SCREW MK9 9965 000 05351
B532 JOINT HOLDER A MK9 9965 000 05352
B533 JOINT HOLDER(B) MK9 9965 000 05353
B534 STOP RUBBER MK9 9965 000 05354
B540 TENSION WASHER MK9 9965 000 05355
B541 REEL WASHER MK9 5*2.1*0.5 9965 000 05342
B550 REV SPRING B MK9 9965 000 05356
B551 FF ARM MK9 9965 000 05357
B553 4822 532 12355
B554 CM CUSHION MK9 9965 000 05711
B555 FF ARM SPACER MK9 9965 000 05712
L1051 SCREW, M2.6X6 PAN HEAD+ 9965 000 05359
L1053 SCREW, M2.6X8 WASHER HEAD+ 9965 000 05375
L1081 M 3 X 6 4822 502 14009
L1101 M 3 X 6 4822 502 14009
2000-07-05 2-6-1 H67T0EL
