Philips VR109/55 - Lead Identifications

LEAD IDENTIFICATIONS
Note:
A: Anode
K: Cathode
E: Emitter
C: Collector
B: Base
R: Reference
S:
Source
G: Gate
D: Drain
A
5
4
8
1
BR24C02F
BR24C02F-W
AT24C02N-10SC
M24C02-MN6
KS24C021CS
LTV-817(A.B.C)-F
PS2561-1 (M.D.H.W)
A
K
C
E
LM324N
1
7
14
8
81
80
31
100
50
30
1
51
LA71592M
QSMA(A,B)0RSN013
2SC2058(Q)
DTA124ESA
KRA103M
KRC103M
DTC124ESA
E C B
BN1F4M-T
BA1F4M-T
KTA1266(Y.GR)
KTC3193(Y)
KTA1267(Y.GR)
2SA1175(J.H.F)
2SA608(E.F)
KTC3199(Y,GR,BL)
2SC2785(J.H.F.K)
2SA933AS(Q,R,S)
2SC1740S(Q,R)
2SC1815-BL (TPE2)
2SC1815-Y(TPE2)
2SC1815-GR(TPE2)
2SC3331(T,U)
2SC2120-Y(TPE2)
2SA1015-GR(TPE2)
E C B
E C B
2SC536NF(NG)-NPA-AT
E C
ST-304L-(A,B,C,D)
E
RPI-302
K
C
S D G
FS2KM-18A
FS1KM-18A
LB11880
1
15
30
16
LC74793-9173
1
12
24
13
1-16-1 H67T0LE
