DISASSEMBLY/ASSEMBLY PROCEDURES
OF DECK MECHANISM
Main Mechanism
Before following the procedures described below, be sure to:
1. Remove the deck assembly from the cabinet.
(Refer to CABINET DISASSEMBLY INSTRUCTIONS on page 1-8-1.)
2. Remove Front Loading Assembly from main mechanism of the deck assembly. (See Fig. DM3)
All the following procedures, including those for adjustment and replacement of parts, should be done in Eject mode;
see the positions of [43] and [44] in Fig. DM1 on page 2-4-3. When reassembling, follow the steps in reverse order.
STEP
/LOC.
No.
START-
ING
No.
PART
REMOVAL INSTALLATION
Fig. No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
ADJUSTMENT
CONDITION
[0] [0] Joint Holder B T DM3 (S-1)
[1] [0]
Front Loading Assembly T DM3 2(S-2),
Rec Arm
(+) Refer to Alignment
Sec. Pg. 2-4-11
[2] [2] Cylinder Shield T DM3 2(S-3)
[3] [3] Deck Grounding Plate T DM3 (S-4)
[4] [2]
Cylinder Assembly T DM1, DM4 3(S-5),
Two Connectors
[5] [5]
Loading Motor Assembly T DM1, DM5 (S-6), LDG Belt (B),
ACH Connector
AN(9P) and B(9P)
[6] [5] Loading Motor Holder T DM1, DM5 2(S-7), *(L-1)
[7] [5] AC Head Assembly T DM1, DM6 2(S-8)
[8] [8] Tape Guide Assembly T DM1, DM6 *(P-1), *(P-2), (C-1)
[9] [9] Door Opener B T DM1, DM6 (S-9), *(L-2)
[10] [9] Pinch Arm (A) Assembly T DM1, DM6 *(P-3)
[11] [10] Pinch Arm (B) Assembly T DM1, DM6 E ring
[12] [8] Capstan Motor B DM2, DM7 3(S-10), Capstan Belt
[13] [13] Cam Gear (B) B DM2, DM8 (C-2)
[14] [14] Center Pulley B DM2, DM8 (C-3)
[15] [15] M Lever Holder B DM2, DM8 (C-4)
[17] [17] Insulation Cap A T DM1, DM9 (S-12)
[18] [17] Mode Lever Holder A B DM2, DM9 (S-13)
[19] [13] Mode Lever A Assembly B DM2, DM9 *2(L-3)
[20] [18]
Mode Gear B DM2, DM9 (C-5), (W-1) (+) Refer to Alignment
Sec. Pg. 2-4-10
[21] [13] Cam Gear (A) B DM2, DM9
[22] [20] Pulley Assembly B DM2, DM9
[23] [21] Worm Holder B DM2, DM9 (S-14)
[24] [23] Insulator Cap B T DM1, DM10 (S-15), *(P-5)
[25] [24] First Post Assembly T DM1, DM10 (S-16)
[26] [25] FE Head T DM1, DM10 (S-17)
[27] [26] Prism T DM1, DM10 (S-18)
[28] [12] TG Post Assembly T DM1, DM10 (S-19), *(L-4)
[29] [28] M Brake T Assembly T DM1, DM11 *(P-6)
[30] [18] M Brake S Assembly T DM1, DM11 *(L-5)
2-4-1 H67T0DA
