Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
35 IN
P-
DOWN-L
Power
Voltage
Down
Detector
Signal
L
36 IN C-SYNC
Composite
Synchronized
Pulse
H/L
37 IN PB-CTL
Playback
Control Signal
H/L
38 IN D-PG
Drum Motor
Pulse
Generator
H/L
39 - GND GND -
40 IN RESET
System
Reset Signal
(Reset="L")
L
41 - GND GND -
42 -
MAIN
CLOCK
Main Clock
13.300857
MHz (IN)
-
43 -
MAIN
CLOCK
Main Clock
13.300857
MHz
-
44 IN D-FG
Drum Motor
Frequency
Generator
H/L
45 IN C-FG
Capstan
Motor
Rotation
Detection
Pulse
H/L
46 - N.U. Not Used -
47 - N.U. Not Used -
48 OUT LM-FWD
Loading
Motor
Forward
Control
(Forward/Stop
="H")
H/L
49 OUT LM-REV
Loading
Motor
Revrese
Control
(Revrese/
Stop="H")
H/L
50 OUT C-CONT
Capstan
Motor Control
Signal
PWM
51 OUT D-CONT
Drum Motor
Control Signal
PWM
52 - N.U. Not Used -
53 - N.U. Not Used -
54 - N.U. Not Used -
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
55 - N.U. Not Used -
56 - N.U. Not Used -
57 - N.U. Not Used -
58 - N.U. Not Used -
59 - N.U. Not Used -
60 - N.U. Not Used -
61 - N.U. Not Used -
62 OUT
REC
LED
REC Mode
LED Indicator
H/L
63 OUT
TIMER
LED
TIMER Mode
LED Indicator
H/L
64 OUT
CAS.
LED
CASSETTE
IN/OUT LED
Indicator
H/L
65 - N.U. Not Used -
66 - N.U. Not Used -
67 - N.U. Not Used -
68 - N.U. Not Used -
69 - N.U. Not Used -
70 - N.U. Not Used -
71 - N.U. Not Used -
72 - N.U. Not Used -
73 OUT
TIMER
LED
TIMER Mode
LED Indicator
H/L
74 - N.U. Not Used -
75 - N.U. Not Used -
76 - N.U. Not Used -
77 - N.U. Not Used -
78 - GND Ground -
79 OUT
OSD
-CS-L
On-Screen
Display IC
Control Chip
Select Signal
at Low
L
80
IN/
OUT
OSD
-DATA
On-Screen
Display IC
Control (Data)
H/L
81
IN/
OUT
OSD
-CLK
On-Screen
Display IC
Control
(Clock)
H/L
82 - N.U. Not Used -
83 - N.U. Not Used -
84 - N.U. Not Used -
85 OUT
REMO-
CON
Remote
control
Sensor
H/L
