Phoenix Contact AXC F 3152 User Manual

AXC F X152
22 / 104
PHOENIX CONTACT 107708_en_09
3.7.2 The controller as a PROFINET controller in a PROFINET
network
Figure 3-4 shows the example of the AXC F 3152 controller as a PROFINET controller in a
PROFINET network.
Figure 3-4 Example: AXC F 3152 controller as PROFINETcontroller
Key:
A PROFINET controller (AXC F 1152, AXC F 2152 or AXC F 3152)
B PROFINET device and switch (in the example: controller with connected Axioline F I/O
modules)
UL
a1 b1
b2b1
UL
a1 b1
b2b1
UL
a1 b1
b2b1
1357
2468
MODE
ACT
SPD
FD
US1 US2
FAI L
LINK
Mode
12345678
X12
V. 24
X9 X10
US1 GND US2 GND R1 R2
X10
MAC
Address
FL SWITCH SMSC 8GT
Ord.. No.2891123
A
PROFINET
B
PROFINET
B
B
For additional information on how to integrate the controller as a PROFINET controller into
a PROFINET network, please refer to the PLCnext Engineer online help.
