Page #45 background image
Mounting hardware
107708_en_09 PHOENIX CONTACT 45 / 104
4.2 Basic information
Mounting location The controller meets the requirements for the IP20 degree of protection. Due to its compact
design, the controller can be installed in standard terminal boxes.
Mounting/DIN rail The controller is mounted on a 35 mm standard DIN rail without any tools using the bus base
module. It is mounted perpendicular to the DIN rail.
The local bus is created automatically when the bus base modules of the controller and
Axioline F devices are installed next to one another.
Supply connector The controller has a supply connector for connecting the power supply. The connector is fit-
ted with spring-cage terminal blocks. When using suitable conductors, the conductors can
be connected by means of direct connection technology (Push-in technology).
FE connection There are two FE springs (metal contacts) on the bottom of the controller which establish
the connection to functional ground when the controller is snapped onto a grounded DIN
rail.
End brackets Mount end brackets on both sides of the Axioline F station. The end brackets ensure that
the Axioline F station is correctly mounted. End brackets secure the station on both sides
and keep it from moving from side to side on the DIN rail. Phoenix Contact recommends the
following end brackets:
Observe the notes on securing the DIN rail and fastening elements as well as the notes
on mounting distances in the UM EN AXL F SYS INST user manual.
For additional information, please refer to Section 5.1.2.
Table 4-1 Recommended end brackets
Mounting position Ambient conditions End bracket
Horizontal; A in
Figure 4-2 on
page 46:
Normal CLIPFIX 35,
CLIPFIX 35-5
High shock and vibration load E/AL-NS 35
Other; B in Figure 4-2
on page 46
Normal E/AL-NS 35
High shock and vibration load
