Description of the controllers
107708_en_09 PHOENIX CONTACT 25 / 104
AXC F 3152
Figure 3-7 Connection and operating elements of the AXC F 3152 controller
The controller consists of the following components:
1 Bus base module
2 Diagnostic and status indicators
3 Electronics module
4 Reset button
5 SD card holder
6 Mode selector switch
7 Service interface (X4) (currently without function)
8 Ethernet interfaces (X1, X2, X3)
9 Supply connector (connector for connecting the supply voltage (communications volt-
age U
L
))
The SD card is optional and not supplied as standard with the controller.
Please refer to the ordering data in Section “Ordering data and technical data” on
page 77.
