AXC F X152
90 / 104
PHOENIX CONTACT 107708_en_09
General data
Color gray
Weight 498 g (with connector and bus base module)
Type modular
Mounting type DIN rail mounting
Module classification PLCnext Control for direct control of Axioline F I/Os.
Application type Distributed control technology
Operating system Yocto/Linux
Processor Intel
®
Atom™ x5-E3930 2x 1.3 GHz
RAM 2048 Mbyte
Flash memory 1 GByte (internal flash memory)
SD card from PhoenixContact (for external flash memory, see
accessories)
Application interface OPCUA
Realtime clock Yes
Controller redundancy yes (applicative system redundancy possible)
External memory yes
Web server yes
Diagnostics display No
Safety function No
Optical interface No
Ambient conditions
Ambient temperature (operation) -25 °C ... 60 °C up to 2000m above mean sea level (observe
derating)
-25 °C ... 55 °C up to 3000m above mean sea level (observe
derating)
≤ 55 °C (with max. 1A on U
Bus
)
> 55 °C ... 60 °C (only in conjunction with an Axioline F power
module AXL F PWR 1H (Item no. 2688297))
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 5 % ... 95 % (according to DINEN61131-2)
Permissible humidity (storage/transport) 5 % ... 95 % (according to DINEN61131-2)
Air pressure (operation) 70 kPa ... 106 kPa (up to 3000m above sea level)
Air pressure (storage/transport) 58 kPa ... 106 kPa (up to 4500m above mean sea level)
Degree of protection IP20
Protection class III (IEC61140, EN61140, VDE0140-1)
Overvoltage category II
Pollution degree 2
Vibration (operation) 5g (according to EN60068-2-6/IEC60068-2-6)
Shock (operation) 30g (according to EN60068-2-27/IEC60068-2-27)
Continuous shock (operation) 10g (according to EN60068-2-27/IEC60068-2-27)
