Phoenix Contact EV Charge Control Basic User Manual

Properties of the charging controller
106377_en_04 PHOENIX CONTACT 7 / 68
Voltage range, supply input
12Va
5 V ... 30 V
Maximum current per output 600 mA
Maximum total current with inter-
nal supply
500 mA
Digital input
Nominal input voltage 12 V
Nominal input current < 1 mA
Input voltage range 0 V … 3 V (OFF) / 9 V … 15 V (ON)
General data
Degree of protection IP20 IP00 IP20 IP00
Overvoltage category III (IEC 60664-1)
Pollution degree 2 (IEC 60664-1)
Ambient temperature
(operation)
-35°C ... +70°C
Ambient temperature
(storage)
-40°C ... +85°C
Humidity
(non-condensing)
30% ... 95%, non-condensing
Altitude < 2000 m
Dimensions W x H x D 124 mm x 128 mm
x 64 mm
120 mm x 108 mm
x 20 mm
124 mm x 128 mm
x 64 mm
120 mm x 108 mm
x 20 mm
Weight 275 g 140 g 260 g 125 g
Connection data
Connection method Screw connection
Nominal cross section 2.5 mm
2
Conductor cross section, solid 0.2 mm
2
... 2.5 mm
2
Conductor cross section,
stranded
0.2 mm
2
... 2.5 mm
2
Stranded conductor cross
section with ferrule without plas-
tic sleeve
0.25 mm
2
... 1.5 mm
2
Stranded conductor cross
section with ferrule with plastic
sleeve
0.25 mm
2
... 1.5 mm
2
Conductor cross section
AWG/kcmil
AWG 24 ... 14
Order number 1622452 1622453 1622459 1622460
EV-CC-AC1-M3- CBC-SER-HS CBC-SER-PCB CC-SER-HS CC-SER-PCB
