Connecting the INTERBUS System
Connect the remote bus cable which goes to the first
INTERBUS bus terminal module (BK module) to the remote
bus interface (REMOTE) on the controller board. The
connection to the controller board is via a 9-pos. D-SUB
female connector, into which you can insert either the remote
bus cable or an adapter for conversion to fiber optic cable. For
further information on the bus cable assembly and optical
fiber adapters, please refer to "Connecting Cable" on page 62
as part of the Appendix.
Use only metal-plated connector housings.
All Phoenix Contact connectors shown in the following
meet these requirements.
