5756B 33
Function Blocks of the Controller
Board
Installing Function Blocks
The disk included in the IBS S7 300 DSC UM E User Manual
contains function blocks in the programming language
STEP 7
®
. Aside from these driver blocks designed for the
operation of the controller board, you will find sample
programs that can be directly linked to your application
program. Functionalities of the controller board are described
in a pre-programmed way, using these sample programs.
For further information concerning the examples
and drivers, please refer to the
IBS S7 300 DSC SWD UM E User Manual (Order No.
27 43 34 7), the text files or the data pre-header in the
examples given on disk.
Contents of the Disk:
Copy the IBSWD312.EXE file to the main directory of the
selected target drive.
IBSWD312.EXE Self-unpacking file
README.TXT Documentation file
