Appendix
Replacing the Controller Board
Only qualified persons should pack, unpack and
handle the controller board while observing the ESD
instructions.
Proceed as follows to replace the controller board:
1. Put the PLC into the STOP state, and switch off the PLC
power supply.
2. Unplug the RS-232 cable, if installed.
Figure 36 Unplugging the RS-232 cable
3. Unplug the remote bus cable.
Figure 37 Unplugging the remote bus cable
5756A 033
5756A 034
