Phoenix Contact RAD IFS Series User Manual

RAD-...-IFS
166 / 198
PHOENIX CONTACT 105542_en_05
Configuration interface
Connection method S-PORT (socket)
RSSI voltage output
Number of outputs 1
Voltage output signal 0 V ... 3 V
RF link relay output
Number of outputs 1
Contact type Changeover contact
Contact material PdRu, gold-plated
Maximum switching voltage 30 V AC/DC / 60 V DC
Maximum switching current 500 mA (30 V AC/DC) / 300 mA (60 V DC)
Electrical service life 5 x 10
5
cycles at 0.5 A at 30 VDC
Connection data
Connection method Screw connection
Conductor cross-section, rigid 0.2 mm² ... 2.5 mm²
Conductor cross-section, flexible 0.2 mm² ... 2.5 mm²
Conductor cross-section, AWG/kcmil 24 ... 14
Stripping length 7 mm
Tightening torque 0.6 Nm
Status indicator
Status indicator Green LED (supply voltage, PWR)
Green LED (bus communication, DAT)
Red LED (peripheral fault, ERR)
3 x green, 1 x yellow LED (LED bar graph for receive quality,
RSSI)
Green LED (RS-232/RS-485 receive data, RX)
Green LED (RS-232/RS-485 transmit data, TX)
Ambient conditions
Ambient temperature (operation) -40°C ... 70°C (>55°C derating)
-40°F ... 158°F (>131°F derating)
Ambient temperature (storage/transport) -40°C ... 85°C
-40°F ... 185°F
Permissible humidity (operation) 20% ... 85%
Permissible humidity (storage/transport) 20% ... 85%
Altitude 2000 m
Vibration (operation) According to IEC 60068-2-6: 5g, 10 Hz ... 150 Hz
Shock 16g, 11 ms
