Phoenix Contact RAD IFS Series User Manual

RAD-...-IFS
46 / 198
PHOENIX CONTACT 105542_en_05
Table 4-7 2.4 GHz RSSI voltage
Table 4-8 868 MHz RSSI voltage
LED bar graph - running light
The running light from bottom to top indicates:
–Firmware update or
– Wireless module in write mode for the memory stick
16k 125k 250k RSSI
voltage
LED 3 -70 dBm -65 dBm -60 dBm ≥2.5 V
LED 2 -80 dBm -75 dBm -70 dBm ≥2.0 V
LED 1 -90 dBm -85 dBm -80 dBm ≥1.5 V
LINK LED LINK LINK LINK ~1.0 V
1.2k 9.6k 19.2k 60k 120k RSSI
voltage
LED 3 -90 dBm -85 dBm -80 dBm -75 dBm -70 dBm ≥2.5 V
LED 2 -100 dBm -95 dBm -90 dBm -85 dBm -80 dBm ≥2.0 V
LED 1 -110 dBm -105 dBm -100 dBm -95 dBm -90 dBm ≥1.5 V
LINK LED LINK LINK LINK LINK LINK ~1.0 V
