IS16

English

7. Equalizer

TheIS16providesa4-bandparametricequalizeroneachinputchannel,Multi1to8outputsandMainMix.Allparametersareadjusted

using the data encoders or touch-screen. Users are able to select a boost or cut of up to 18 dB on frequencies between 20 Hz and 20kHz.

A31-bandequalizerisalsoavailableontheMainoutput,andcanbeselectedbyenteringthePatchmenuandchangingtheOrdersettings

toincludetheGEQinsteadoftheEQ.TheQofthesesignalscanalsobeadjustedtogiveawiderornarrowerband,asnecessary.

7.1 Signal Source

Hereuserscanselectwhichchannel’sEQtoset.Anequalizercanbeappliedtoanyoftheinputchannels,anyoftheMultioutputsand

the main mix.

7.2 EQ On/Off Button

This button can turn the Equalizer for the currently selected channel on and off.

7.3 EQ Grid/Curve

HereuserscanviewtheEQcurve.Thesmallcirclesthatappearonthegraphrepresentoneofthefourbands,andcanhelptoeffectively

adjustthefrequencyandboost/cutpropertiesofthatparticularband.Thetouchscreencanbeusedtohelpadjustthebands.

7.4 EQ Band On and Off

UsethesebuttonstoturnthecorrespondingEQbandsonandoff.Whilenotnamedspecically,thesebandscanbethoughtofasthelow,

low-mid,high-midandhighfrequencybandsonyouraverage4-bandEQ.

7.5 EQ Type

FortherstandfourthbandsontheEQ,userscanselectthetypeofcurveusedfortheEQ.

Band1:EQBand(PEAK),LowShelfFilter(SHELF),HighPassFilter(CUT)

Band4:EQBand(PEAK),HighShelfFilter(SHELF),LowPassFilter(CUT)

TheLow/HighPassFilterswillcutfrequenciesaboveandbelowtheselectedfrequenciesat18dBperoctave.HighandLowShelflters

actsimilarly,butcutfrequenciesbelowtheselectedfrequencybythepresetleveldeterminedbytheuser.

7.6 EQ Parameters

TheEQoffersuserstheabilitytovieworeditvariousparameters/propertiesoftheirEQbands,includingtheGain,thefrequencyandthe

‘Q’oftheEQfrequency.Thefollowingparametertableoffersdetailsontherangeavailabletousersoneachparameter.

Parameter 1 (Low) 2 (Low-Mid) 3 (High-Mid) 4 (High)

Gain -18 dB to 18 dB

Frequency 20 Hz to 20 kHz

Q 10to0.1,HPF,Shelf 10 to 0.1 10to0.1,LPF,Shelf

7.7 EQ In / Out Level Meters

These level meters give visual representations of levels going into and out of the equalizer.

Phonic IS16v1 User Manual
