11.3 DATA TR A N SFER AND V I S U ALIZATION
1. Once kinetics protocol data (OJIP, NPQ, LC) has been collected by the FluorPen it needs to be downloaded to PC
to be visualized. Fig. 21 below shows example of an OJIP and NPQ protocol data.
2. Click the Download icon or select Device > Download.
3. Once download is complete the Data table appears as shown below in Fig 21.
