INSTALLING THE ELECTRICAL CIRCUIT
Specification
Desc./Quantity
1 Installing the electrical circuit To the plafoniera
2 Installing the electrical circuit Choke device diagnostic port
3 Installing the electrical circuit Battery restraining belt
4 Installing the electrical circuit Seat opening actuator
B 125-250 Electrical system
ELE SYS - 75
