about 500 cc
Locking torques (N*m)
Oil relief screw 15 ÷ 17
Removing the flywheel magneto
- Undo the screw indicated and remove the plate.
- Install the support plate.
Specific tooling
020916Y Magneto flywheel blocking tool
- Install the specific tool and unscrew the retainer
nut of the flywheel, recovering the washer.
Specific tooling
020627Y Flywheel lock tool
Beverly 400 E5 Engine
ENG - 117
