- Insert the Seeger ring.
- Insert the alignment dowels if removed during
disassembly.
Removing the driven pulley
To remove the driven pulley, proceed as follows:
- Remove the drive pulley to release the drive belt.
- Remove the driven pulley together with the belt.
WARNING
AS A RESULT OF THE OPERATION THERE MAY BE A
LIGHT "HAMMERING" BETWEEN THE KNURLING OF THE
PULLEY AXLE. THIS CAN MAKE REMOVAL BY HAND DIF-
FICULT.
IN CASE OF NEED USE AN EXTRACTOR.
Removing the clutch
- To remove the clutch assembly it is necessary to
remove the inlet pinion to the final reduction unit,
operating as described in the section «Dismount-
ing the hub cover».
Beverly 400 E5 Engine
ENG - 87
