- Working from the automatic transmission side,
remove the driven pulley.
- Unscrew the six fixing screws from the clutch
cover.
- By using two screwdrivers work on the appendi-
ces and remove the cover taking care not to drop
the clutch assembly.
- Remove the clutch assembly.
Inspecting the clutch
COVER REVISION
- Adequately support the cover and using a screw-
driver remove the seal ring.
Specific tooling
001467Y007 Driver for OD 54-mm bearings
Engine Beverly 400 E5
ENG - 88
