PIAGGIO Beverly 400 E5 - Rear Suspension

TRANSMISSIONS AND BRAKES
Name Torque in Nm
Brake pipe retainer clamp - Engine 10.5 ± 0.5 Nm
Throttle control transmission fixing nut - Throttle body 5.5 ± 0.5 Nm
Brake pipe retainer clamp - Frame 10.5 ± 0.5 Nm
Gas transmission retainer clamp - Frame 10.0 ± 1.0 Nm
Brake pipe retainer clamp - Fork 10.5 ± 0.5 Nm
ABS control unit - ABS control unit support bracket 9.0 ± 1.0 Nm
Ground cable - ABS control unit 9.0 ± 1.0 Nm
Brake pipes - ABS control unit 18.5 ± 1.5 Nm
ABS control unit support bracket - Frame 10.5 ± 0.5 Nm
Ground cable - ABS control unit support bracket 8.5 ± 1.0 Nm
Front brake pipe - Front brake master cylinder 22.5 ± 2.5 Nm
Brake pipes bracket clamp - ABS control unit bracket 5.0 ± 1.0 Nm
Rear brake pipe - Rear brake pump 22.5 ± 2.5 Nm
Rear brake pipe - Rear brake calliper 22.5 ± 2.5 Nm
Front brake pipe - Front brake calliper 22.5 ± 2.5 Nm
REAR SUSPENSION
Beverly 400 E5 Technical Data
DT - 25
