PIAGGIO Beverly 400 E5 - Overhaul Data; Assembly Clearances

LOCKS
Name Torque in Nm
Saddle opening actuator support bracket - Frame 6.0 ± 1.0 Nm
Saddle-lock - Helmet compartment 6.0 ± 1.0 Nm
Glove-box opening rocker - Frame 6.0 ± 1.0 Nm
Overhaul data
Assembly clearances
Cylinder - piston assy.
Technical Data Beverly 400 E5
DT - 32
