REAR SUSPENSION
Name Torque in Nm
Rear shock absorber - Engine 42.5 ± 2.5 Nm
Rear ABS sensor - Engine 7.0 ± 1.0 Nm
Silent block bracket - Frame 71.0 ± 4.0 Nm
Rear wheel - Rear wheel axle 113.0 ± 11.0 Nm
Rear brake calliper - Engine 47.0 ± 5.0 Nm
Mudguard frame - Engine 22.5 ± 2.5 Nm
Swingarm bushing - Frame 6.0 ± 1.0 Nm
Swingarm - Silent block bracket 98.0 ± 10.0 Nm
Swingarm - Frame 52.5 ± 2.5 Nm
Engine side swinging arm - Chassis side swinging arm 42.5 ± 2.5 Nm
Swinging arm on engine side - Engine 58.0 ± 2.0 Nm
Rear shock absorber - Chassis 42.5 ± 2.5 Nm
Right rear shock absorber bracket - Silencer support arm 22.5 ± 2.5 Nm
ELECTRICAL SYSTEM
Beverly 400 E5 Technical Data
DT - 27
