PIAGGIO Beverly 400 E5 - Removing the Rocker-Arms Cover

- Remove the sleeve connecting the throttle body.
Removing the rocker-arms cover
- Support the big end cover.
- Unscrew and remove the special cover fastening
screws.
- Remove the big end cover.
Removing the timing system drive
- Before working on the timing system it is recom-
mended to place the engine at TDC in compres-
sion, aligning the references as shown in the
figure.
Beverly 400 E5 Engine
ENG - 121
