PIAGGIO Beverly 400 E5 - Removing System Components

2 Bleeder pipe
3 Pipe for connecting the canister to the inlet fitting
4 Canister valve
5 Pipe for connecting the fuel tank to the canister
6 Breather valve
Removing system components
Remove the helmet compartment and the side fairings to gain access to the components of the evap-
orative emissions control system.
