- Working from the opposite side, supporting the
cover, proceed to the removal of the bearing.
Specific tooling
001467Y007 Driver for OD 54-mm bearings
020376Y Adaptor handle
020358Y 37 x 40 mm Adaptor
- Heat the crankcase by means of specific tools
and then insert a new bearing.
- Using the equipment plant a new bearing, apply
grease on the adapter and guide in order to main-
tain the position of the bearing during operation on
the vertical axis.
Specific tooling
020151Y Air heater
020376Y Adaptor handle
020360S 52 x 55 mm adaptor
020364Y 25-mm guide
- Insert a new seal ring and grease the seal lips.
Specific tooling
020376Y Adaptor handle
020360S 52 x 55 mm adaptor
- Replace the outer O-ring and grease properly.
WARNING
IN ORDER TO PREVENT ABNORMAL FORMATIONS OF
DIRT DUE TO THE RELEASE OF GREASE, WE RECOM-
MEND FIRST LUBRICATING THE SEAL RING STOPS WITH
A BRUSH.
Beverly 400 E5 Engine
ENG - 89
