Refitting
- - Insert the oil pump with the corresponding gas-
ket in the seat.
- Insert and tighten the oil pump fastening screws
to the crankcase to the specified torque.
Recommended products
Loctite 243 Medium strength thread-locking
sealant.
Blue
Locking torques (N*m)
Screws fixing oil pump to the crankcase 5 ÷ 6
Beverly 400 E5 Engine
ENG - 147
