PIAGGIO Beverly 400 E5 - Page 29

ELECTRICAL SYSTEM
Name Torque in Nm
MIUG4 control unit connection retainer clamp - Throttle body 7.0 ± 1.0 Nm
Earth braid - Engine 8.5 ± 1.0 Nm
Starter motor ground - Starter motor 12.0 ± 1.0 Nm
Positive cable connection - Starter motor 7.0 ± 1.0 Nm
ENGINE
Beverly 400 E5 Technical Data
DT - 29
