- Disengage the upper ring of the specific tool.
- Remove the outer ring with the seat for the Bel-
leville spring.
- Remove the Belleville spring.
- Remove the spring door upper disc.
- Remove the discs separation spring.
- Remove the semi-trimmed duct disc (trimmed on
one side).
- Remove a conductor disc.
- Remove the discs clearance recovery spring
- Remove a duct metallic disc.
- Remove a conductor disc (trimmed on both
sides).
