CAUTION
THE CLEARANCE RECOVERY SPRING DISCS ARE FIT-
TED INDIVIDUALLY.
THE FIRST IN THE ASSEMBLY PHASE MUST BE POSI-
TIONED TOWARDS THE INSIDE OF THE HOUSING, AS
SHOWN IN FIGURE.
- Remove the hub.
- Remove the shaft.
Engine Beverly 400 E5
ENG - 94
