fuse as shown in Figure 2-15.
Figure 2-15
[Step 4]
Remove the broken fuse and replace a new one with the same type or same
rating as shown in Figure 2-16.
Figure 2-16
[Step 5]
Insert the fuse holder back and turn it left as shown in Figure 2-17. Make
sure the fuse holder is properly seated and secured.
Current input Fuse
Fuse
Current Fuse Holder
