Picotest M3500A - Page 9

9
[Step2]
Turn off the power and disconnect the line cord from your multimeter as
shown in Figure 2-1. Also, you should remove all the leads connected to it.
Figure 2-1
[Step 3]
Open the cap and remove the voltage setting selector from the right middle
seam as shown in Figure 2-2. (You might need a flat-blade screwdriver to
do so.)
Figure 2-2
Window
