Commissioning
Operating Manual PNOZ m B1
1003790-EN-02
| 21
6.3.4 RJ45 connection cable
RJ45 connector
8-pin
8
1
10BaseT cable or 100BaseTX cable
max. 100 m
NOTICE
With the plug-in connection please note that the data cable and connector
have a limited mechanical load capacity. Appropriate design measures
should be used to ensure that the plug-in connection is insensitive to in-
creased mechanical stress (e.g. through shock, vibration). Such measures
include fixed routing with strain relief, for example.
