Commissioning
Operating Manual PNOZ m B1
1003790-EN-02
| 24
Move multifunction switch up or down
} Select menu
6.7.2 Displays and settings
The LC display has five lines. Information is shown on the display and settings can be
made.
The field at the top right of the display shows information about the connection and instruc-
tions for the menu settings:
12:00
Legend:
Network connection/traffic
USB memory inserted
12:00 System time
Press the multifunction switch to go back to the higher level menu
Press the multifunction switch to access the sub-menu
Hold the multifunction switch down for 4 s to confirm the selection or perform the
action
i
Press the multifunction switch to obtain information
Press the multifunction switch to call up the system message
Press the multifunction switch to call up the user message
