Commissioning
Operating Manual PNOZ m B1
1003790-EN-02
| 28
6.7.2.3
Device Info menu
Display
Example
Description
Device Info
Device info
Pos Baseunit
PNOZ m B1
Device info
Pos x/n
EF 8DI4DO
>
>
01
.
00
01
.
00
Information on the base unit and ex-
pansion modules. Overview:
}
Position/slot
}
Device type
}
Firmware version
Device information
for module
Baseunit
Product number:
773200
Serial number
123456
Baseunit
SW channels:
A 01.02
Baseunit
HW:
01.00
B 01.02
C 01.02
Baseunit
Operating hours
1234
Show device information for a selec-
ted module:
}
Order number
}
Serial number
}
Software versions
}
Hardware version
}
Operating hours
27
29
Table of Contents
Default Chapter
3
Table of Contents
3
1 Introduction
5
Validity of Documentation
5
Using the Documentation
5
Definition of Symbols
5
2 Overview
7
Range
7
Unit Features
7
USB Memory
7
Front View
8
3 Safety
9
Intended Use
9
System Requirements
10
Safety Regulations
10
Safety Assessment
10
Use of Qualified Personnel
10
Warranty and Liability
10
Disposal
10
For Your Safety
11
4 Function Description
12
Integrated Protection Mechanisms
12
Functions
12
System Reaction Time
12
Detection of Shorts Across Contacts
13
Block Diagram
14
Diagnostics
14
Ethernet Interface
14
5 Installation
15
Control Cabinet Installation
15
Mounting Distances
15
Dimensions in MM
17
Connecting the Base Unit and Expansion Modules
17
6 Commissioning
19
General Wiring Guidelines
19
Connection
19
Ethernet Interfaces
20
RJ45 Interfaces ("Ethernet")
20
Requirements of the Connection Cable and Connector
20
Interface Configuration
20
RJ45 Connection Cable
21
Use USB Memory
22
Load Project from Pnozmulti Configurator
22
Activate Project Via the Display on the Base Unit
23
Display Settings
23
Operate Menu
23
Displays and Settings
24
Status Indicators
25
Project Menu
26
Device Info Menu
28
Error Stack Menu
29
Operating Info Menu
29
Connections Menu
30
Ethernet Menu
30
Time Menu
32
System Mode Menu
32
Function Test During Commissioning
32
7 Operation
33
LED Indicators
33
Show Error Stack on the Display
34
8 Technical Details
35
Safety Characteristic Data
37
9 Order Reference
38
Product
38
Accessories
38
